Kioti KL120 - Installing Front Grill and Boom Assembly

LOADER INSTALLATION 14-3
Install Front Grille
1 Front Grill - 1EA
2 Hex Head Bolt M12X1.75Px40L - 4EA
Spring Washer ø 12 - 4EA
Hex Head Nut M12X1.75P - 4EA
120OE02A 120OE03A
Install Boom Ass'y
Hang the groove on the pin located on outer bearing box.
(1) Bearing Box (2) Bearing Inner Box
