Kioti KL701 - Page 61

PART ILLUSTRATIONS 13-5
REF. NO PART. NO DESCRIPTION QTY I.C REMARK
13
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
FTQU6-10000
FTQU6-10100
FTQU2-10200
FTQU2-10300
FTQU2-10301
14132-20185
14232-36032
14224-28181
FTQU2-11003
10191-M1606-90
10261-M1606
1021N-M1606
10316-M1600
10321-M1600
10191-M1004-35
1021N-M1004
802G0-T1900
FTBU3-82300-01
14131-30155-N
1021M-M3006
Quick Attachment Ass`y - Euro Hitch Type(No.1~16)
Quick Attach Frame
Lever W.A-Quick
Link W.A-Quick
Link-Quick
Pin W.A-Quick
Spring
Spring
Grip-Rubber
Hex Bolt, M16-P2.0 90L
Hex Bolt, M16-P2.0
Nut-Selock, M16-P2.0
Washer-Spring, M16
Washer-Plain, M16
Hex Bolt, M10-P1.5 35L
Nut-Selock, M10-P1.5
Nipple, Grease, 1/8"
Bucket W.A - ISO (82")
Pin, Ø30-155L
Nut-Selock, M30-P2.0
1
1
1
1
1
2
1
1
1
1
1
1
1
2
4
4
2
1
4
4
