SPECIFICATIONS
EXTERNAL DIMENSIONS
※
These dimensions are measured
with the standard tires installed to
the ROPS model tractor.
621O301a
※
A1 : Overall length including weight and 3 point hitch / A2 : Overall length excluding weight
ITEM
MODEL
ITEM
MODEL
L3503 LK45 L3503 LK45
1. Overall length (A1) 3,510 (138.2) 5. Wheel base (D) 1,780 (70.1) 1,792 (70.6)
2. Overall length (A2) 3,153 (124.1) 6. Front wheel tread (E) 1,130 (44.5) 1,165 (45.9)
3. Overall width (B) 1,460 (57.5) 1,480 (58.3) 7. Rear wheel tread (E)
1,024 ~ 1,414
(40.3 ~ 55.7)
1,066 ~ 1,440
(42.0 ~ 56.7)
4. Overall height (C) 2,140 (84.2) 2,415 (95.1) 8. Groundclearance (F) 336 (13.2) 370 (14.6)
mm(in.)
