Keep the generator away from other electric cables or wires
such as commercial power supply lines.
DC receptacle is availabe for DC power
The total power shouldn't exceed the sum of AC and DC
power if AC and DC power are used at same time.
For most equipment, the motor needs the power higher
than rated value for starting
6.1 AC applications
1. Start the engine and make sure the output indicator light (green) comes on.
2. Confirm that the appliance to be used is switched off, and plug in the appliance.
Overload indicator lamp (red) is on for a long while,
generator may be damaged; although overload indicator lamp
is on a short while, the generator service lift may still be
shortened.
Be sure that all appliances are in good working order
before connecting them to the generator. If an appliance
begins to operate abnormally, becomes sluggish, or stops
suddenly, turn off the generator engine switch immediately.
Then disconnect the appliance, and examine it for signs of
malfunction.
6.2 Output and Overload Indicators
1. In normal condition, ouput indicator lamp (green) is on
Ouput indicator lamp (green)
Overload alarm lamp(red)
Low oil level alarm lamp(red)
Over speed alarm lamp (red)
2. If generator overloads (more than 5.5kVA), or loads have short circuit ouput
indicator lamp (green) will be off while overload lamp(red) will be on. At this time the
current to loads will be cut off
Ouput indicator lamp (green)
Overload alarm lamp(red)
Low oil level alarm lamp(red)
Over speed alarm lamp (red)
If red lamp is on, stop the engine and find out the reason.
Check the load condition before they are connected to the
generator
Red and green lamp may be on at the same time during
geneartor starting. If red lamp is off after 4 seconds, it means
the generator is in normal; if the red lamp still keeps on,
please contact KIPOR dealer.
3. Low oil level alarm
This system is designed for protecting engine due to lackage of oil. It will stop the
engine automatically if the oil level of crankshaft box is below the safe value. (generator
switch still keeps in "ON" position). If customers restart the engine, the alarm lamp(red)
will twinkle, and the engine can't be started. Please add the oil in this condition.
Ouput indicator lamp (green)
Overload alarm lamp(red)
Low oil level alarm lamp(red)
Over speed alarm lamp (red)
4. Over speed alarm
Generator will stop at once and alarm lamp will be on if engin is over speed for (0.5 3
seconds).
Ouput indicator lamp (green)
Overload alarm lamp(red)
Low oil level alarm lamp(red)
Over speed alarm lamp (red)
To avoid spark, please connect the charge cable to
generator first, then connect the battery. During dismantling,
remove the battery first.
Do not confuse the + and - pole, or the generator and
battery will be damaged.
For car battery charge application, disconnect the battery
earth cable before connecting to the generator. During
dismantling, disconnect the charge cable before earthing,
which will prevent the short circuit and spark.
Do not start the car if the genetor sill keep connecting with
the car.
CAUTION
WARNING
WARNING
WARNING
DANGER
