8.4 SPARK ARRESTOR MAINTENANCE
■If the generator has been running, the muffler will be very hot. Allow
it to cool before proceeding.
■The spark arrestor must be serviced every 100 hours to maintain its
efficiency.
1. Remove the four 5 mm screws, and remove the muffler protector.
2. Remove the there 6 mm bolts, and remove the muffler, the spark arrester and the muffler gasket
