Kipor IG2000 Operation Manual

42
12. SPECIFICATIONS
Generator
Model
IG2000 /IG2000p
Rated frequency (Hz)
60
Rated voltage (V) 120
Rated current (A) 13.3
Max current (A) 16.6
Rated output (W) 1600
Max output (W) 2000
DC Output 12 V, 5.0 A
Phase Single
Engine
Model KG158
Type Single cylinder, 4 stroke, vertical shaft, air-cooled, OHV,
gasoline engine
Displacement 3.3 cu in (105 cc)
Compression ratio 8.5:1
Engine speed 4300~4500 RPM with smart throttle off
Ignition system T. C. I
Spark plug UR5
Starting system Recoil starter
Fuel Automotive unleaded gasoline
Lube oil SAE 10W30 (above CD grade)
Oil Capacity .42 qt (0.4 L)
Fuel tank capacity 0.9 gal (3.4 L)
Rated load run time 3.3 hours
Noise level- dB @ 23 feet (7 m) 54~59 NL-FL
Tune Up Specifications
Spark Plug Gap 0.024-0.028 in (0.6-0.7 mm)
Valve Clearance (Intake) 0.0031-0.0039 in (0.18-0.10 mm)
Valve Clearance (Exhaust) 0.0039-0.0059 in (0.10-0.15 mm)
Dimensions
Overall dimension (L×W×H) in (mm)
20.27 × 11.81 × 16.93 in
(515 × 300 × 430 mm)
Dry weight 48.4 lbs (22 kg)

Kipor IG2000 Specifications

General

Rated Power	1.6 kW
Voltage	230 V
Frequency	50 Hz
Fuel Type	Gasoline
Starting System	Recoil
Weight	22 kg
Engine Type	4-stroke, OHV
Noise Level	54-59 dB(A)
Continuous Operation Time	4 h (at rated load)
