9. SPECIFICATIONS
18
10. WARRANTY – Terms & Conditions
The water pump as standard original equipment is covered by this warranty from the date of
original retail purchase for a period of 2 years for residential use and 1 year for commercial
applications. Water Pumps used in rental fleets or as demonstration models will be considered
commercial usage. The warranty coverage is continual from the original date of purchase, and
does not restart upon the replacement of any part or complete unit. Individual parts replaced at
any point during the warranty period are only eligible for warranty coverage for the balance of the
original warranty period.
Eligibility:
To be eligible for warranty service, the product must be purchased in Australia from an authorised
Kipor dealer. This warranty applies to the original retail purchaser only, and is not transferable.
The original Proof of Purchase is required.
To obtain warranty service:
Contact any authorised dealer or Primus Australia Pty Ltd Bundoora Victoria 3083:
Phone 1300 555 197
Fax 1300 555 198
E-mail: enquires@primusaustralia.com.au
Website: www.primusaustralia.com.au
Please Note:
To perform any warranty service or assessment, the authorised dealer will require the original Proof
of Purchase and a record of the water pump’s serial number.
Exclusions:
This warranty does not extend to parts affected or damaged by accident and/or collision, normal
wear, fuel contamination, use in an application for which the product was not designed or any
other misuse, neglect, incorporation or use of unsuitable attachments or parts, unauthorised
alteration, or any causes other than defects in material or workmanship of the product. This
warranty does not extend to normal maintenance items such as spark plugs and filters.
Irrespective of whether warranty is approved or rejected, the following costs are not covered under
this warranty policy: Fares, charter fares, car hire, freight, tolls, hire or loan equipment, loss of
earnings or stock and medications.
19
Model High Volume Water
Transfer KDP20/KDP20E
High Volume Water
Transfer KDP30/KDP30E
High Volume Water
Transfer KDP40/KDP40E
Suction port (mm) dia 50mm (2”) 75mm (3”) 100mm (4”)
D
ischarge port (mm) dia 50mm (2”) 75mm (3”) 75mm (4”)
Rated flow (max) 600L/min 900L/min 1250L/min
Total Head (max) 26m 25m 31m
Suction head (max) 8m 8m 8m
S
elf-priming time at 4am 80sec 120sec 180sec
Dry weight (kg) 35kg 52kg 69kg
Overall dimension (mm) 525 x 410 x 515mm 510 x 445 x 550mm 650 x 480 x 600mm
Starting system Recoil starter
E: Electric start
Recoil starter
E: Electric start
Recoil starter
E: Electric start
Engine Model KM170 KM178 KM186
Engine type Single cylinder,
4 stroke, vertical,
direct injection diesel
Single cylinder,
4 stroke, vertical,
direct injection diesel
Single cylinder,
4 stroke, vertical,
direct injection diesel
Displacement (cc) 211cc 296cc 406cc
Bore x Stroke (mm) 70 x 55mm 78 x 62mm 86 x 70mm
Rated power 4.2hp 6.0hp 9.0hp
Cooling system Forced air-cooled Forced air-cooled Forced air-cooled
Noise level - dB(A)7m 74 76 79
Fuel tank (Lt) 2.5L 3.5L 5.5L
Fuel Diesel fuel Diesel fuel Diesel fuel
Lube oil (Lt) 0.75L 1.1L 1.62L
