Trunked POC Portable Two-way Radio Quick Reference Guide
10
Refer to the illustration for the location of the following connectors, controls, buttons and keys:
(1) Programmable side button 1
(2) PTT button
(3) Programmable side button 2
(4) Antenna
(5) Speaker
(6) Top key
(7) Channel selector knob
(8) Power/Volume knob
(9) LED status indicator
(10) Microphone
(11) Rugged accessory connector (RAC) with cover (screw fixing)
Micro USB slot and earphone slot
(12) Belt clip accessory
(13) Battery
(14) Battery latch
