KIRLOSKAR Non-Clog Submersible Series - Page 22

22
This is a proprietary document of Kirloskar Brothers Limited,
YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune
–
411045, India.
NS IOM MANUAL
1
Sept
2018
9.9 CROSS SECTIONAL VIEW OF NS PUMP UNIT III – Q TYPE IMPELLER (SDS)
DEL.
SUC.
OIL
9.10 CROSS SECTIONAL VIEW OF NS PUMP UNIT IV & ABOVE (SDS)
