KIRLOSKAR Non-Clog Submersible Series User Manual

23
This is a proprietary document of Kirloskar Brothers Limited,
YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune
–
411045, India.
NS IOM MANUAL
1
Sept
2018
9.10. Pump Part list
PARTCD
PARTDESC
PARTCD
PARTDESC
10700
PUMP CASING
59005
STUD FOR BEARING COVER
13001
STATOR HOUSING
59006
STUD FOR PUMP CASING AND SUCTION PLATE
15100*
ENCLOSED IMPELLER
59008
STUD FOR UPP BRG HOLDER AND ST HOUSING
15300*
SEMIOPEN IMPE
LLER
62100
WASHER FOR IMPELLER NUT
16401
ROTOR WITH SHAFT
63001
RELEASE SCREW FOR MECH SEAL HSG/LOW BRG HOLDER/MOT END COV
18900
SHAFT
63002
HEX RELEASE SCREW FOR SUCTION PLATE
19000*
CASING RING
64001
RIVET FOR OIL NAME PLATE
20900
SPACER FOR SUCTION
PLATE
64002
RIVET FOR DUTY NAME PLATE
22401
HOSE CLIP FOR POTTING CUP FOR POW+CON CABLE
66900*
SCREW FOR IMPELLER
22402
HOSE CLIP FOR POTTING CUP FOR POWER CABLE
67000
DUTY NAME PLATE
22501
BUSH FOR POWER+CONTROL CABLE
-
DOL
67300
OIL NAME PLATE
22503
BU
SH FOR POWER CABLE
-
SDS
68200*
GASKET FOR IMPELLER SCREW
23000*
DOUBLE MECHANICAL SEAL
69200
HEX NUT FOR FOUNDATION BOLT
24600
CABLE BRACKET
70101
SPRING WASHER FOR NUT OF LOW BEARING HOLDER AND CASING
25600
LOWER BEARING HOLDER/MECH SEAL HOUSING
70102
S
PRING WASHER FOR NUT OF LOW BRG HOLDER AND ST HOUSING
25700
UPPER BEARING HOLDER
70103
SPRING WASHER FOR MOTOR END COVER AND STATOR HOUSING
26001*
DEEP GROOVE BALL BEARING LOWER
70105
SPRING WASHER FOR BEARING COVER
26002*
DEEP GROOVE BALL BEARING UPPER
70107
SPRING WASHER FOR STAND NUT
27100
BEARING COVER FOR LOWER BEARING
82800
STUD FOR GUIDE SHOE
28300
DUCK FOOT BEND
84000
WASHER FOR NUT FOR FOUNDATION BOLT
30400
FOUNDATION BOLT
84501
WAHSER FOR POWER+CONTROL CABLE
32000*
KEY FOR IMPELLER
84502
WA
SHER FOR POWER CABLE
33000*
IMPELLER NUT
84504
WASHER FOR PROTECTION TUBE POWE+CONT CABLE
34100
TIE ROD FOR STAND
-
PORTABLE
84505
WASHER FOR PROTECTION TUBE POWE CABLE
35000
STUFFING BOX BUSH
84900
WASHER FOR EARTHIN SCREW
38300
SUPPORT PLATE FOR STAND
-
PORTABLE
84901
WASHER FOR TERMINAL BOARD
44001
POTTING CUP FOR POWER+CONTROL CABLE
-
DOL
85600
SPRING WASHER FOR HEX SCREW FOR PUMP CASING AND GUIDE SHOE
44003
POTTING CUP FOR POWER CABLE
-
SDS
85700
NUT FOR GUIDE SHOE
44400
PLUG FOR INSPECTION
88400
TIE FO
R CABLE
46000*
WEAR PLATE
88501
PIN TYPE LUG
-
FOR CONTROL CABLE
46500*
SUCTION PLATE
88502
PIN TYPE LUG FOR POWER CABLE
47100
PROTECTION COVER FOR DELIVERY
88504
CRIMPING RING TERMINALS FOR CONTROL CABLE
47101
PROTECTION CAP FOR SCREW
88505
CRIMPING RIN
G TERMINAL FOR POWER CABLE
47900
HELICOIL LOCK INSERT FOR IMPELLER SCREW
90901
MOTOR END COVER
48600
EXTERNAL CIRCLIP FOR LOWER BEARING
91100
STATOR
-
F CLASS STD
50900
CABLE BRACKET
91201
TERMINAL BOARD
51100*
GASKET FOR PUMP CASING & LOW BRG HOLDER/MEC
H SEAL HSG
91301
POWER+CONTROL CABLE
52301*
O
-
RING FOR UPPER BEARING HOLDER / STATOR HOUSING
91302
POWER CABLE
52302*
O
-
RING FOR LOWER BEARING HOLDER / STATOR HOUSING
91401*
CABLE SEAL FOR POWER+CONTROL CABLE
52303*
O
-
RING FOR OIL FILLING PLUG/INSPECTIO
N
91402*
CABLE SEAL FOR POWER CABLE
52304*
O
-
RING FOR SUCTION PLATE/WEAR PLATE
91500
HANDLE
52305*
O
-
RING FOR FOR MOTOR END COVER
91800
GUIDE SHOE
52306*
O
-
RING FOR STUFFING BOX BUSH
91900
RUBBER DIAPHRGAM
52307*
O
-
RING FOR COOLING CHAMBER
92000
STAND
52308*
O
-
RING FOR INSPECTION PLUG
92800
GUIDE PIPE HOLDER
55901
GUIDE PIPE ADAPTOR
93200
MOISTURE SENSOR
55902
ADAPTOR PIECE FOR GUIDE PIPE
93800
THERMISTOR
58201
HEX NUT FOR STUD OF PUMP CASING AND LOW BRG HOLDER
94100
GUIDE PIPE
58202
HEX NUT FOR LO
W BRG HOLDER AND STATOR HOUSING
94300
HEX NUT FOR TERMINAL BOARD
58203
HEX NUT FOR MOTOR END COVER AND STAT HOUSING
97801*
PROTECTION TUBE FOR POWER+CONTROL CABLE
58204
HEX NUT FOR BUSH AND MOTOR END COVER
-
SDS
97802*
PROTECTION TUBE FOR POWER CABLE
5820
5
NUT OF BEARING COVER
98900
HEX. SOCKET HEAD CAP SCREW FOR STUFFING BOX BUSH
58206
NUT FOR SUCTION PLATE
98901
HEX SOC CAP SCREW FOR EARTHING
58207
NUT FOR STAND
98903
HEX SOC CAP SCREW FOR GUIDE PIPE ADAPTOR
58208
HEX NUT FOR STUD OF UPPER BEARING HOL
DER
98904
HEX SOC CAP SCREW FOR ST HOUSING AND LOW BRG HOLDER
59001
STUD FOR PUMP CASING AND LOW BRG HOLDER
98905
HEX SOC CAP SCREW FOR ST HOUSING AND MOTOR END COVER
59002
STUD FOR LOW BRG HOLDER AND STATOR HOUSING
98906
HEX SCREW FOR CABLE BRACKET
590
03
STUD FOR STATOR HOUSING AND MOTOR END COVER
98907
HEX SCREW FOR BEARING COVER
59004
STUD FOR BUSH AND MOT END COVER
-
SDS
* Marked part code nos. are recommended spares.
