5
Product Dimensions
Side View
■ The depth from the front of the top grille to the back of the
refrigerator cabinet is 25¹⁄₈" (64 cm).
■ The power cord is 84" (213 cm) long.
■ The water line attached to the back of the refrigerator is 5 ft.
(1.5 m) long. Height dimensions are shown with leveling legs
extended ¹⁄₈" (3 mm) below the rollers.
*When leveling legs are fully extended to 1¹⁄₄" (32 mm) below
rollers, add 1¹⁄₈" (29 mm) to the height dimensions.
Top View
Pro Line
TM
Series
Features extraordinary design and exceptional levels of
performance. This series is a perfect blend of form and function
delivering professional quality, durability and simplicity.
KBRV36FPM KBRV36FPS KBLV36FPM
KBLV36FPS
25¹⁄₈"
(64 cm)
23¹⁄₂"
(60 cm)
84" (213 cm)
Power Cord
*83¹⁄₈"
(211 cm)
*3
¹⁄₂" (9 cm)
25¹⁄₈"
(64 cm)
35⁷⁄₁₆"
(90 cm)
To Next Page
