KitchenAid 5KSMSCA - Preparing to Process Cucumbers;Zucchini

12 | USING THE VEGETABLE SHEET CUTTER ATTACHMENT
USING THE VEGETABLE SHEET
CUTTER ATTACHMENT
3
Insert the food holder into one end,
then the zucchini/cucumber adapter
into the other, using the markings to
align both holder and adapter. Make
sure the food holder and adapter
are centred.
4
Place the food and food holder
onto the main body and twist
clockwise to lock into place.
PREPARING TO PROCESS CUCUMBERS/ZUCCHINI
NOTE: Please refer to the “Fruit & vegetable prep”chart before processing.
TIP: The first mark on the food skewer
is 4.5"(11.4 cm) from the round
skewer base.
1
Rotate lever clockwise to the
locked position.
2
Cut cucumber or zucchini to a
maximum length of 4.5"
(11.4 cm).
