KitchenAid 720-0709C - Detailed Part List

11Bottom panel5811Tempered glass fix panel29
Part List
Part
Number
Part (description)
Warranty
Cover
age
Quantity
Part
Number
Part description)
Warranty
Coverage
Quantity
1 Main lid 3 1 30 Tempered glass 1 1
2 Main lid screw 1 2 31 Control knob bezel 1 6
3 Temperature gauge seat 1 1 32 Control knob 1 6
4 Temperature gauge 1 1 33 Light switch 1 1
5 Main lid handle seat, left 1 1 34 Sear burner lid 1 1
6 Main lid handle seat, right 1 1 35 Sear burner lid handle 1 1
7 Main lid handle tube 1 1 36 Sear burner lid hinge 1 2
8 Warming rack 1 1 37 Sear burner cooking grid 3 1
9 Cooking grid with hole 3 3 38 Sear burner 1 1
10 Flame tamer 1 5 39 Sear burner grease tray 1 1
11 Burner Pin assenbly 1 5 40 Sear burner igniter wire 1 1
12 Main burner 10 5 41
Sear burner bowl
assembly
11
13 Main burner igniter wire A 1 1 42 Side shelf, left 1 1
14 Main burner igniter wire B 1 1 43 Hooks 1 6
15 Main burner igniter wire C 1 1 44 Side shelf end cap, left 1 1
16 Main burner igniter wire D 1 1 45 Side shelf front panel, left 1 3
17 Main burner igniter wire E 1 1 46 Side shelf, right 1 1
18 Main lid bracket, right 1 1 47 Side shelf end cap, right 1 1
19 Main lid bracket, left 1 1 48
Side shelf control panel,
right
13
20
Main burner bowl
assembly
Non-
replaceable
1 49 Back panel 1 1
21 Front baffle 1 1 50 Rubber grommet 1 1
22 Main gas valve 1 5 51 Firebox support 1 1
23 Searing gas valve 1 1 52 Heat shield, left 1 1
24 Main manifold 1 1 53 Electronic igniter modular 1 1
25 Regulator LP 1 1 54 Side panel, right 1 1
26 Control panel light 1 1 55 Heat shield, right 1 1
27 Main control panel 1 1 56 Grease box 1 1
28 Logo 1 1 57 Clapboard 1 1
