KitchenAid 720-0990C (LP) - Parts List; Detailed Part Descriptions and Warranty

Parts List
94
No. Part (Description)
Warranty
coverage
(year)
QTY No. Part (Description)
Warranty
coverage
(year)
QTY
1A Main lid screw
1 2
40A Cart side panel, left
1 1
2A Temperature gauge
1 1
41A Cart heat shield panel
1 1
3A
Temperature gauge housing
1 1
42A Cart side panel, right
1 1
4A Hood buffer A
1 2
43A Battery box
1 1
5A Main lid
3 1
44A Electric igniter module
1 1
6A Main lid handle assembly
3 1
45A Cart frame assembly, front
1 1
7A Side shelf, left
3 1
46A Upper door bracket
1 2
8A Side shelf control panel, left
3 1
47A Door magnet
1 2
9A Grease tray handle
1 1
48A Caster
1 2
10A Grease tray
1 1
49A Bottom panel
1 1
11A Warming rack
1 1
50A Swivel caster with brake
1 1
12A Cooking grid with hole
1 3
51A Swivel caster
1 1
13A Flame tamer
1 5
52A Bottom panel trim piece
1 1
14A Burner pin assembly
1 5
53A Gas tank slide bracket, left
1 1
15A Main burner
10 5
54A Gas tank slide
1 2
16A Main burner igniter wire A
1 1
55A
Tan
k tray
1 1
17A M
ain burner igniter wire B
1 1
56A Gas tank slide bracket, right
1 1
18A Main burner igniter wire C
1 1
57A Gas tank block piece
1 1
19A Main burner igniter wire D
1 1
58A Thumb screw
1 2
20A Main burner igniter wire E
1 1
59A Door hinge bracket, left
1 1
21A Main burner bowl trim piece
1 1
60A Cart trim piece , left
1 1
22A Main burner bowl assembly
Non-
replaceable
1
61A Tank tray bolt
1 1
23A Firebox heat shield
1 1
62A Secondary tank bracket
1 1
24A Front baffle
1 1
63A Door hinge bracket, right
1 1
25A Control panel heat shield
1 1
64A Cart trim piece , right
1 1
26A Main control panel
3 1
65A
Grease cup
1 1
27A Ground wire
1 1
66A Grease cup bracket
1 1
28A Logo
1 1
67A Door hinge
1 4
29A LED light switch
1 1
68A Door, left
3 1
30A LED light wire harness
1 1
69A Door, right
3 1
31A Regulator, LP
1 1
70A Door handle assembly
3 2
32A Main gas valve
1 5
71A Lighting rod
1 1
33A
Main manifold
1 1
72
N
G conversion kit
Sold separately as a
set
34A Igniter junction wire
1 1
72.1
NG gas hose with quick connector
assembly
Sold
separately
as a set
with #72
1
35A
Gas quick connector
1 1
72.2 NG regulator assembly
1
36A Bezel A
1 5
72.3 Truss head screw with lock
2
37A
Control knob A
1 5
72.4 Flat washer
2
38A Rear panel
1 1
72.5 6mm Hex wrench
1
39A NG hole rubber plug
1 1
72.6 6mm nut driver
1
