Parts List
98
No. Part (Description)
Warranty
coverage
(year)
QTY No. Part (Description)
Warranty
coverage
(year)
QTY
1B Side control panel 3 1 30B Sear burner support 1 1
2B LED light switch 1 1 31B Firebox for side burners
Non-
replaceable
1
3B LED light 1 3 32B Side burner insert 1 1
4B Side burner manifold flex gas line 1 1 33B Cart side panel, left 1 1
5B Side burner gas valve 1 2 34B Rear panel 1 1
6B Side burner manifold 1 1 35B Cart side panel, right 1 1
7B LED light wire harness 1 1 36B
Ground wire for side burner
module
1 1
8B Bezel 1 3 37B Cart trim piece , left 3 1
9B Control knob 1 3 38B Cart frame assembly, front 1 1
10B Side burner lid
3
1 39B Battery box 3 1
11B Side burner lid hinge rod
1
1 40B Electric igniter module 3 1
12B Side burner lid hinge assembly
1
2 41B Cart trim piece , right 3 1
13B Drawer assembly, upper
1
1 42B Swivel caster with brake 3 2
14B Drawer assembly, bottom 1 1 43B Swivel caster 3 2
15B Side burner lid shield 1 2 44B Bottom panel 3 1
16B Side burner bowl frame
3
1 45B Bot
tom panel trim piece 3 1
17B Side burner orifice 1 2 46B Drawer handle assembly 1 2
18B Side burner cooking grid 1 2 47B Side shelf, right 1 1
19B Sear burner cooking grid 1 1 48B Grease tray 1 1
20B Sear burner gas valve 1 1 49B Side shelf control panel, right 1 1
21B Side burner 1 2 50B Grease tray bracket 1 1
22B Sear burner 1 1 51B Tool hook 1 2
23B Side burner flex gas line A 1 1 52B Drawer slide bracket 3 4
24B Side burner flex gas line B 1 1 53B Drawer slide 1 4
25B Side burner igniter wire A 1 1 54B NG orifice pack 3 1
26B Side burner igniter wire B 1 1 54B.1 Sear burner burner orifice 1 1
27B Sear burner igniter wire 1 1 54B.2 Side burner burner orifice 1 1
28B Side burner support 1 2 Grill Cover 1
29B Side burner bowl assembly 1 1 Manual 1
