KitchenAid 730-0856 - Page 48

*Natural gas conversion kit sold separately
48
Part
Number
Part (Description)
Warranty
coverage (year)
QTY
Part
Number
Part (Description)
Warranty
coverage (year)
QTY
61 Side panel, right 1 1 84 Sear side burner lid 1 1
62
Door hinge supporting
brackets, left
1 1 85 Sear side burner cooking grate 1 1
63 Cart frame 1 1 86 Sear side burner 1 1
64 Gas tank tray slide bracket,A 1 1 87 Sear side burner igniter wire 1 1
65 Gas tank tray slide 1 2 88 Sear side burner grease tray 1 1
66 Door magnet 1 2 89 Sear side burner bowl assembly 1 1
67 Gas tank tray 1 1 90 Sear side control panel 1 1
68 Gas tank tray block piece 1 1 91 Lighting rod cover 1 1
69 Tank tray bolt 1 1 92 Sear side burner pin assembly 1 2
70 Tank tray slide bracket,B 1 1 93 NG orifice pack
sold separately as
set
1
71 wheel axle 1 1 93a Rotisserie burner NG orifice
φ1.84
1 1
72 Wheel cap 1 2 93b Sear side burner NG orifice φ1.9 1 1
73 Wheel 1 2 94 NG conversion kit
sold separately
as set
1
74 Axletree seat 1 2 94a NG regulator assembly for NG unit 1 1
75
Door hinge supporting
brackets, right
1 1 94b
NG gas hose with quick connector
assembly for NG nuit
1 1
76 Cart frame, right 1 1 94c 6mm Nut driver 1 1
77 Lighting rod 1 1 94d 6mm socket head wrench 1 1
78 Door hinge 1 4 94e 6mm Wrench 1 1
79 Cart frame, left 1 1 94f Flat washer 1 2
80 Door, left 1 1 94g Truss head screw with lock 1 2
81 Door, right 1 1 PVC cover 1 1
82 Door handle assembly 1 2 Manual 1
83
Sear side burner lid support
bracket
1 2
Parts List
