KitchenAid 730-0856 - Parts List

47
Part
Number
Part (Description)
Warranty
coverage
(year)
QTY Part Number Part (Description)
Warranty
coverage
(year)
QTY
1 Main lid 1 1 31 Shaft collar 1 1
2 Main lid screw 1 2 32 Front Baffle 1 1
3 Temperature gauge housing 1 1 33 Logo 1 1
4 Temperature gauge 1 1 34 Regulator LP 1 1
5 Main lid handle 1 1 35 Main gas valve 1 6
6 Side shelf,left 1 1 36 Igniter junction wire 1 1
7 Utensil hook 1 6 37 Rotisserie burner gas valve 1 1
8 Side shelf control panel 1 1 38 Main manifold 1 1
9 Warming rack 1 1 39 Sear side burner flex gas line 1 1
10 Cooking grid 3 4 40 Sear side burner gas valve 1 1
11 Flame tamer 1 6 41 Sear side burner manifold 1 1
12 Rear buffer 1 1 42 Main control panel 1 1
13 Rotisserie burner heat shield 1 1 43 Bezel 1 6
14 Rotisserie burner 1 1 44 Control knob 1 7
15 Rotisserie burner ignition wire 1 1 45
Control knob bezel, Rotisserie
burner
1 1
16
Rotisserie burner igniter
bracket
1 2 46 Control knob, Rotisserie burner 1 1
17 Burner pin assembly 1 6 47 Main burner grease box 1 1
18
Rear burner orifice with brass
elbow
1 1 48 Igniter wire cover 1 1
19 Rear burner flex gas line 1 1 49 Back panel 1 1
20 Main burner 10 6 50 Gas tank heat shield 1 1
21 Main burner igniter wire A 1 2 51 Clapboard A 1 1
22 Main burner igniter wire B 1 2 52 Clapboard B 1 1
23 Main burner igniter wire C 1 2 53 Electronic igniter module cover 1 1
24 Lid bracket, left 1 1 54 Clapboard C 1 1
25 Lid bracket, right 1 1 55 Side panel, left 1 1
26 Main burner bowl assembly
Non-
replaceable
1 56 Door hinge supporting brackets 1 2
27 Rotiesserie motor 1 1 57 Swivel caster with brake 1 1
28 Rotiesserie motor bracket 1 1 58 Swivel caster 1 1
29 Spit rod 1 1 59 Bottom panel 1 1
30 Spit fork 1 4 60 Electronic igniter modular 1 1
Parts List
