No. Part (Description)
Warranty
coverage
(year)
QTY No. Part (Description)
Warranty
coverage
(year)
QTY
1
Main lid 1 1 28
Charcoal tray adjustment L shape
bracket, left
1 1
2
Main lid hinge 1 2 29
Charcoal tray adjustment L shape
bracket, right
1 1
3
Chimney lid 1 1 30
Charcoal tray raising rod fixing
bracket
1 2
4
Charcoal Chimney 1 1 31
Charcoal tray adjustment
assembly
1 1
5
Temperature gauge housing 1 1 32
Charcoal tray adjustment
assembly support bracket
1 2
6
Temperature gauge 1 1 33 Stage screw B 1 4
7
Main lid handle seat 1 2 34 Charcoal ash tray 1 1
8
Main lid tube 1 1 35
Charcoal ash tray handle
assembly
1 1
9
Cooking grid lifter 1 1 36 Left cart leg, back 1 1
10
Cooking grid with hole 3 3 37 Left cart leg, front 1 1
11
Charcoal bowl assembly
Non-
replaceable
1 38 Swivel caster with brake 1 1
12
Main control panel 1 1 39 Swivel caster 1 1
13
Ventilation adjustment bracket 1 1 40 Firebox support side panel 1 2
14
Stage screw A 1 4 41
Charcoal ash tray support
bracket, side
1 2
15
Logo 1 1 42
Charcoal ash tray support
bracket, middle
1 1
16
Ventilation door control knob 1 1 43 Firebox support rear panel 1 1
17
Ventilation panel 1 1 44 Side shelf, right 1 1
18
Charcoal tray control knob 1 1 45 Right cart leg, back 1 1
19
Side shelf support bracket A 1 2 46 Right cart leg, front 1 1
20
Side shelf trim piece, left 1 1 47 Wheel 1 2
21
Side shelf support bracket B 1 2 48 Wheel cap 1 2
22
Side shelf stage screw 1 8 49 Bottom panel cross bar A 1 2
23
Side shelf hook 1 4 50 Bottom panel cross bar B 1 2
24
Side shelf, left 1 1 51 Bottom panel 1 1
25
Warming rack 1 1 52 Cart beam, front 1 1
26
Charcoal tray 1 1 53 Heat shield panel 1 2
27
Charcoal tray support 1 1 54 Side shelf trim piece, right 1 1
PARTS LIST
45
