5. Use an adjustable wrench to remove the brass elbow.
6. Use a 6 mm socket wrench or 6 mm nut driver to remove
the orifice. Replace with the corresponding natural gas
orifice.
IMPORTANT: Check that the NG orifice is properly
installed inside the valve.
7. Reinstall the rotisserie burner brass elbow by using a
wrench.
8. Reinstall the igniter bracket and tighten the screws.
9. Reinstall the rotisserie burner rear cover.
10. Reinstall the six screws onto the rotisserie burner rear
cover.
11. Reinstall the rotisserie burner heat shield.
12. Tighten the two screws.
