6
PRODUCT ASSEMBLY
Place the Bowl* on the Clamping Plate
and twist to lock in place.
3
Slide and rotate the accessory aligning
over the pin on the shaft.
4
Unlock the Motor Head and move it
down. Then, lock** the head to keep
it down. Before mixing, test lock by
attempting to raise the Motor Head.
5
(OPTIONAL) To adjust Beater to Bowl
Clearance: Tilt and lock** the Motor
Head back. Turn the screw slightly
counterclockwise (left) to raise the
beater, or clockwise (right) to lower it.
NOTE: If you over-adjust the screw, the
Bowl lock lever may not lock into place.
(OPTIONAL) Place the Pouring
Shield***: Slide the Pouring Shield***
from front of the Stand Mixer over the
Vowl. The bottom rim of the Pouring
Shield*** fits inside of the Bowl*.
*The Bowl design and material depend on the Stand Mixer model.
**Locking option is available on selected models.
***Included with select models only. Also available as an optional accessory.
