6
PRODUCT ASSEMBLY
Place the bowl on the clamping plate
and twist to lock in place.
3
Slide and rotate the accessory aligning
over the pin on the shaft.
4
Unlock the motor head and move it
down. Then, lock the head to keep
it down. Before mixing, test lock by
attempting to raise the motor head.
5
(OPTIONAL) To adjust beater to bowl
clearance: Tilt and lock the motor
head back. Turn the screw slightly
counterclockwise (left) to raise the
beater, or clockwise (right) to lower it.
NOTE: If you over-adjust the screw, the
bowl lock lever may not lock into place.
(OPTIONAL) Place the pouring shield*:
Slide the pouring shield* from front of
the Stand Mixer over the bowl. The
bottom rim of the pouring shield* fits
inside of the bowl.
*Included with select models only. Also available as an optional accessory.
