KitchenAid KBFC42FSS00 - Top Grille and Unit Cover Components

TOP GRILLE AND UNIT COVER PARTS
4
For Model: KBFC42FSS00
(Stainless Steel)
W10044170
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 2313983S Top Grille
Assembly
2 2320502 Cover, Unit
3 2317881 Grille, Condenser
4 2256466 Back Panel
5 2307682 Front,
Unit Cover
6 487415 Screw
7 2187946 Wire Assembly,
Light Switch
8 2215910 Grommet, Flexible
9 489348 Clamp
10 2317066 Nameplate
11 2004333 Nut
