KitchenAid KBLS36FMB01 - Top Grille and Unit Cover Parts; Top Grille Assembly; Unit Cover and Panel; Fasteners and Clamps

TOP GRILLE AND UNIT COVER PARTS
4
For Models: KBLS36FMB01, KBLS36FMX01
(Black) (Etched Aluminum)
8199164
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 Top Grille
Assembly
2259425B Black
2259425X Etched Aluminum
2 2259320 Cover, Unit
4 2256466 Back Panel
5 2302974 Front,
Unit Cover
6 487415 Screw
7 2187423 Wire Assembly
9 489348 Clamp
10 Trim−Grille,
Bottom
2259438B Black
2259438X Etched Aluminum
11 Trim−Grille,
Right Side
2259420B Black
2259420X Etched Aluminum
12 Trim−Grille, Top
2259440B Black
2259440X Etched Aluminum
13 Trim−Grille,
Left Side
2259421B Black
2259421X Etched Aluminum
14 2003347 Screw
15 1161548 Nut
