Tip OverHazard
A chitdor adult can tip the range
and be killed.
Connect anti-tip bracket to walt
behind range.
Reconnect the anti-tip bracket, if
the range is moved.
Failure to follow these instructions
can result in death or serious
burns to chitdren and adults.
line I
I
I
._j wall stud
I
I
I
_ mounting
screws
I
I
I
I
Position top of anti-tip bracket at
line marked in step 5 and mark holes.
Drill two 1/8" (3 mm) holes. Use screws
provided to fasten anti=tip bracket to wall.
NOTE: Anti=tip bracket must be mounted
securely to stud in wall behind the range.
Depending on thickness of the wall
covering, longer screws may be required.
mMake electrical connection.
if your house has aluminum wiring, see
"Electrical requirements" page 5.
Electrical Shock Hazard
Turn power supply off before
connecting wires.
Use 8 gauge solid copper wire.
Electrically ground range.
Failure to follow these instructions
can result in death, fire, or
electrical shock.
This range must be connected to a
grounded, metallic permanent wiring
system or a ground connector shoutd
be connected to the ground terminat
or wire lead on the range.
This range is manufactured with a frame-
connected, green or bare ground wire
factory-crimped to the neutral (white)
wire. Connect the range cable to the
junction box through the U=L=or CSA=
listed conduit connector. Complete
electrical connection according to local
codes and ordinances.
Am Where Iocat codes Do Not
permit connecting the frame-ground
conductor to the neutral (white)
junction box wire: (Also used for
Canadian installations}.
4owire cable from power supply
b.reordeen b ac.wire,
w_ree _J \ U.L.- or CSA= listed
/ conduit connector
4-wire cable from range
Ungrounded neutra_
Figure 1
1. Disconnect power supply.
2. Connect the flexible, armored cable
from the range to the junction box
using a U=L- or CSA-iisted conduit
connector. Tighten screws on conduit
connector.
3. Connect the two black wires
together; and the two red wires
together using twist-on connectors.
(See Figure 1.)
4. Separate the factory-crimped bare
and white range cable wires.
5. Connect the two white wires together
using twist=on connector.
6. Connect the bare ground wire from
the range cable to the grounded wire
in the junction box or other grounded
connector using twist-on connector.
(See Figure 1.)
Do Not connect bare ground wire
to neutrat (white) wire in junction
box.
m Where local codes permit
connecting the frame-ground
conductor to the neutral (white)
junction box wire. (Not used for
Canadian installations):
3-wire cable from
junction power supply
box_ _ black
J--" w,r0s
white _ _ir_Au
wire_
white and bare
grounding oven cable
wires -- factory [t
cdmpe_
4-wire cable from/range
Grounded neutra_
Figure 2
1. Disconnect power supply.
2. Connect the flexible, armored cable
from the range to the junction box
using a U.L= or CSA=listed conduit
connector. Tighten screws on conduit
connector.
3. Connect the two black wires together;
the two red wires together; and the
factory-crimped bare and white
cooktop cable wires to the white
(neutral) wire in the junction box using
twist=on connectors. (See Figure 2.)
m Remove cardboard or hardboard
from under range.
To Next Page
