KitchenAid KECS100 - Caring for Your Cooktop; Coil Elements and Reflector Bowls

9
Caring for Your Cooktop
Coil elements and reflector bowls
Removing
3. Pull the coil element straight away
from the receptacle.
4. Lift out the reflector bowl. See the
“Cleaning chart” later in this section
for cleaning instructions.
H
I
L
O
O
F
F
M
E
D
M
E
D
H
I
M
E
D
L
O
WARNING
Explosion Hazard
Do not store flammable materials such as gasoline near
this appliance.
Doing so can result in death, explosion, or fire.
1. Make sure all coil elements are off and
cool before removing coil elements and
reflector bowls.
2. Push in the edge of the coil element,
opposite the receptacle. Then lift it
just enough to clear the reflector bowl.
Replacing
1. Make sure all coil elements are off and
cool before replacing coil elements
and reflector bowls.
H
I
L
O
O
F
F
M
E
D
M
E
D
H
I
M
E
D
L
O
