KitchenAid KESMK5 - Parts and Features

2
PARTS AND FEATURES
1 Storage container
2 Milk dispenser tube
3 Function knob
4 Steam port
5 Froth level adjustment knob
6 Brush
7 Milk tank lid
8 Milk hose
9 Milk tank
10 Milk hose connector
11 Milk hose clip
12 Hot water function
13 Hot milk function
14 Froth milk function
1
5
3
4
2
11
7
9
8
12 13 14
10
6
