13
English
Setting Up Your Food Processor
Installing Other Slicing or
Shredding Discs
1. Holding the desired disc by the 2 nger
grips, insert the slicing/shredding adapter
into the hole in the bottom of the disc.
2. Slide the drive adapter into the slicing
adapter as far as it will go, until it clicks
into place.
IMPORTANT: The optional julienne and
plane/shave discs can only be installed in
one direction. When using the reversible
shredding disc, have the desired side
(medium/ne) facing UP.
3. With the work bowl installed, slide the
drive adapter onto the power shaft.
4. Install the work bowl cover, being sure it
locks into place.
TIP: You may need to turn the disc/drive
adapter until it drops down into place.
