ASSEMBLING THE FOOD PROCESSOR
Installing the reversible shredding disc or french fry disc
1
Hold the french fry disc or reversible
shredding disc by the 2 finger grips with
the desired shredding side facing UP.
Insert the disc adapter into the hole in
the bottom of the disc.
2
With the work bowl installed, slide the
drive adapter onto the power shaft.
TIP: You may need to turn the disc/adapter until it drops down into place.
ASSEMBLING THE FOOD PROCESSOR
Installing the multipurpose blade or dough blade
1
Place the blade on the power shaft.
Rotate the blade so it falls into place on
the power shaft.
IMPORTANT: The multipurpose blade and dough blade can only be used with
the work bowl.
Finger Grip Finger Grip
2
Push to lock: Press down firmly on the
multipurpose blade until it is down as
far as it will go. The multipurpose blade
features an internal seal that fits tightly
over the center of the work bowl.
3
Install the work bowl cover, being sure
it locks into place.
