KitchenAid KFXS25RYMS - Door Removal & Replacement

7
Drawer Front Removal
A. Loosen 2 Drawer Glide Bracket Screws
B. Remove 2 Drawer Glide Bracket Screws
A
B
Drawer Front Replacement
Door Removal & Replacement
Top Hinges
A. Hinge Cover Screw
B. Top Hinge Cover
C.
5
/ 16 " Hex Head Hinge Screws
D. Top Hinge
A. Hinge Pin Cover
C. Hinge Screws
B. Bottom Hinge
Bottom Hinges
A
B
C
B
A
C
D
Connections
A
B
A. Wiring Plug
B. Water Line Connection
1
A.
3
/ 32 " or
1
/ 8 " Setscrew
A
2
A.
3
/ 32 " or
1
/ 8 " Setscrew
A
