Model KGCC566 (36" [91.4 cm] shown)
Model KGCC506 (30" [76.2 cm] not shown)
Control Panel
Cooktop
A. Left front burner control knob
B. Control knob off position
C. Left rear burner control knob
D. Center rear burner control knob
(on 36" [91.4 cm] models only)
E. Right rear burner control knob
F. Right front burner control knob
A. 17,000 Btu/h burner
B. Surface burner cap
C. Left surface burner grate
D. 6,000 Btu/h burner (9,100 Btu/h burner
on 30" [76.2 cm] models)
E. Model and serial number plate
(under cooktop)
F. 9,100 Btu/h burner
(on 36" [91.4 cm] models only)
G. Center grate
H. 12,500 Btu/h burner
I. Right surface burner grate
J. 6,000 Btu/h burner
K. Control panel
