KitchenAid KHID4 65510 - Installation Diagrams

4
Installation diagrams
235 mm
235 mm
483 mm
553 mm
30 mm
+1
0
580/585 mm
650/655 mm
700/705 mm
510/515 mm
52 mm
R = Min. 6,5 mm
Max. 8 mm
490 mm
560 mm
0
+2
0
+2
513 mm
583 mm
0
+2
0
+2
6 mm
560 mm
490 mm
R = 11,5 mm
R = Min. 6,5 mm
Max. 8 mm
R = 11,5 mm
0
+2
0
+2
Min. 50 mm
Min. 5 cm
Min. 10 cm
Min. 3 cm
Max. 6 cm
5 mm
