KitchenAid KHIP4 77510 - Installation Diagrams

4
Installation diagrams
180 mm
280 mm
180 mm 145 mm
Min. 5 cm
Min. 10 cm
Min. 3 cm
Max. 6 cm
R = Min. 6,5 mm
Max. 8 mm
490 mm
750 mm
0
+2
0
+2
Min. 50 mm
513 mm
Min
. 50 mm
773 mm
0
+2
0
+2
750 mm
490 mm
R = 11,5 mm
0
+2
0
+2
6 mm
R = 11,5 mm
R = Min. 6,5 mm
Max. 8 mm
