The electrical connections must comply with current
legislation and be carried out by a qualified, competent
person.
• Information on the voltage and power absorbed are shown on the
serial no. plate.
• The appliance must be earthed.
• When installing the appliance, we recommend that this hob is
protected by a 3mm bi-polar switch.
• If damaged, the power cable must be replaced with an
identical type of powercable ( H05V2V2-FT90 ºC, or H05RR-F
type). We recommend that this operation be conducted by
our After Sales Service. Please contact our Customer Care
Centre on 00800-3810-4026.
• Do not use extension cables.
• The manufacturer declines all responsibility for damage to
persons, pets or goods as a result of failure to comply with the
regulations above.
Electrical connection
L
Earth
(yellow/green)
N
After having cleaned the perimeter surface, apply the supplied gasket to the hob as shown in
the figure.
Position the hob in the worktop opeing made respecting the dimensions indicated in the instruction.
Note: the power supply cable must be long enough to permit its upward extraction.
To secure the hob, use the brackets (A) provided with it. Fit the brackets into the relevant bores shown by
the arrow and fasten them by means of their screws in accordance with the thickness of the worktop (see
the following figures).
Installation
10
