DISPENSER FRONT PARTS
14
For Models: KSCK25FVWH01, KSCK25FVBL01, KSCK25FVSS01, KSCK25FVMS01
(White) (Black) (Stainless Steel) (Monochromatic Stainless)
W10251931
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 Housing, Dispenser
(Not Serviced)
2 3196537 Screw
3 2194719 Retainer, Levers
4
W10224328 Spring, Torsion
5 2196195 Pin
6 2180353 Door, Ice
7 2304355 Door Mechanism
Assembly
8 2205686 Mechanism Delay
9 Grille, Overflow
W10189531 White
W10189532 Black
W10171993 Midnight Grey
10 2221562 Water Fitting
Assembly (Includes
Water Tube)
11 Lever, Ice
Dispenser
W10152853 White
W10152854 Black
W10155161 Apollo Gray
12 2180224 Guide, Ice
13 2305571 Gasket
14
W10245284 LED Assy, Bracket
15
W10206221 Bracket, Control
16 625834 Spacer, Switch
17 Lever, Water
Dispenser
W10152858 White
W10152859 Black
W10155162 Apollo Gray
18 2162361 Switch, Ctrl
19 Bezel, Disp
W10136850 White
W10136851 Black
W10139842 Stainless
20 Fascia Assy, Disp
W10136810 White
W10144770 Black
W10144818 Stainless
21
W10194025 Gasket, Disp (2)
22
W10141632 Screw
23
W10170417 Support, Window
24 2304673 Bracket, Dispenser
25 2195051 Strain Relief
26 3400065 Screw
28 489214 Screw, Disp (2)
29
W10160662 Ctrl−Elek, UI
