CABINET PARTS
2
For Models: KSCK25FVWH01, KSCK25FVBL01, KSCK25FVSS01, KSCK25FVMS01
(White) (Black) (Stainless Steel) (Monochromatic Stainless)
W10251931
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10168296
Use & Care Guide
W10203129
Service & Wiring
Sheet
2318510 Installation
Instructions
W10216524
Energy Guide
2220407 Modular Icemaker
Service Sheet
2 Front Roller Asm
2306950 Left Side
2306951 Right Side
3 2223263 Strap, Roller
4 2306949 Roller, Rear (2)
5 2223388 Clip, Retainer (4)
6 2155013 Clip, Grille
7
W10001260
Screw
8 2223545 Shim
9 Hinge Top, RC
2307008W White
2307008B Black
2307008AP
Apollo Gray
10
W10142235
Screw
11
W10151272
Screw
12 2307179 Hinge Assembly,
Bottom−RC
(Includes #29)
13 Filler, Wrapper
2223893W White
2223893B Black
2223893AP
Apollo Gray
14 Grille
W10194047
White
W10194057
Black
W10194061
Midnight Grey
15
W10142286
Screw
16 Hinge, Top FC
2307007W White
2307007B Black
2307007AP
Apollo Gray
17
W10001250
Screw
18 2304888 Drain Fitting
19 2254566 Tube, Extension
20
W10146358
Screw
21 2223409 Cover, Unit
22 2223387 Pin, Roller (4)
23 549193 Clamp, Service
Cord
24
W10141645
Screw
25 2307152 Hinge Assembly,
Bottom−FC
(Includes #32)
26 Button, Water
Filter
2260503W White
2260503B Black
2260503MG
Midnight Grey
27
W10121140
Housing, Water
Filter
28 4396841 Water Filter
29 2307049 Door Closer, RC
30 Cap, Water
Filter
2260502W White
2260502B Black
2260502MG
Midnight Grey
31 Cabinet (Not A
Serviceable Part)
32 2307051 Door Closer, FC
33
W10142234
Screw
35
W10142288
Screw
36 2224020 Tube, Filter
Outlet
37 2319867 Tube, Filter
Inlet
To Next Page
