CONTROL PARTS
16
For Models: KSCK25FVWH01, KSCK25FVBL01, KSCK25FVSS01, KSCK25FVMS01
(White) (Black) (Stainless Steel) (Monochromatic Stainless)
W10251931
Illus. Part
No. No. DESCRIPTION
1 2223882 Heat Shield Asm
(Includes #3)
2 2223506 Light Lens,
Control Box
3 2223857 Light Socket
4 2326255 Light Bulb
