ENGLISH
USING THE METAL FOOD GRINDER ATTACHMENT | 5
USING THE METAL FOOD GRINDER ATTACHMENT
ASSEMBLING THE METAL FOOD GRINDER ATTACHMENT
1
Insert the grind screw into the main housing. Then,
place the blade over the end of the grind screw.
The blade should t entirely inside the housing. If it
doesn’t, pull it off, turn it over, and place it again.
2
Place grinding plate over the blade, matching the
notch of the plate with the tab on the bottom of the
main housing.
3
Place the collar on the main housing, turning clockwise
by hand until secured but not tightened.
Wash all parts with warm, soapy water and dry thoroughly before use.
ATTACHING THE METAL FOOD GRINDER ATTACHMENT TO THE
STAND MIXER
1
Turn the Stand Mixer off and unplug.
2
For Stand Mixers with a hinged attachment hub
cover: Flip up to open.
For Stand Mixers with a removable attachment hub
cover: Turn the attachment knob counterclockwise to
remove attachment hub cover.
3
Insert the attachment shaft housing into the
attachment hub, making certain the power shaft ts
into the square hub socket. If necessary, rotate the
attachment back and forth. The pin on the attachment
housing will t into the notch of the hub rim when in
the proper position.
Tab
Notch
