5
PRODUCT USAGE
Insert the Grind Screw into the Main
Housing securely.
1
ASSEMBLING THE FOOD GRINDER ATTACHMENT
Place the Blade over the end of the Grind
Screw.
2
ASSEMBLING THE SLICER/SHREDDER ATTACHMENT
Place the desired Grinding Plate over the
Blade, matching the notch of the plate with
the tab on the bottom of the Main Housing.
3
Place the Collar on the Main Housing,
turning clockwise by hand until secured but
not tightened.
4
Unplug and turn the Stand Mixer off (0).
Slide the blade you want to use into the
housing. You will hear a click when the blade
snaps into place properly on the drive shaft.
Notch
Tab
Sharp Side
1 2
