Remove Packaging Material Inside the Grill
1. Cut the tiedowns holding the grates together.
2. Remove condiment shelf, warming shelf and grill
grates from inside the grill and remove packaging
material.
3. Remove foam block and wrap from inside the grill.
A Foam block
B Foam wrap
4. Replace the grill grates.
5. Place warming shelf on brackets as shown.
A Warming shelf brackets
B Warming shelf
6. Attach condiment shelf to the inside of the left
cabinet door.
A Attachment holes
B Attachment holes
7. Dispose of/recycle all packaging material.
Tank tray installation instruction
Unpack the carton and take out accessories with plastic bag, remove bag.
1. Fix tank tray to the cart base with 4-5/32"*10 screws, Torque spec: 25kgf.cm
2. Mount the tank metal loop to th cart base with 3-1/4"*12, torque spec: 54kgf.cm.
Note: do not fix the hook to the other end of the loop until the tank is positioned into the tray. Step 3
3. Fix the hook to the end of the loop.
