ICEMAKER PARTS
26
For Model: KSSC36QMS02
(Stainless Steel)
8214657
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
2 2300104 Cover−Bottom,
Electrical
3 2187622 Wire Assembly,
Icemaker
5 628379 Clip, Fuse
6 2214613 Tube, Filter Inlet
7 2316756 Water Inlet
Tube Assembly
8 2302758 Seal Gasket
9 2302719 Tube, Filter
Outlet
10 2307811 Valve, Solenoid
12 2221070 Clamp, Tube
14 2198641 Bracket, Icemaker
Cover
15 2208136 Clamp, Nylon
Valve
16 488937 Clamp Tube
17 2259417 Tube, Water Inlet
18 2257538 Cover
20 2212351 Mold & Heater
(Also Order
542638 Silicone
Grease)
21 Motor− (Not
Serviceable−Order
Item #35)
22 628356 Cup−Water Fill
23 2212320 Ejector
24 2212318 Ice Striper
25 2194712 Support
26 627796 Retainer
Thermostat (2)
27 627985 Thermostat
(Also Order
542639 Cement
Alumilastic)
28 8533917 Screw
30 489276 Screw
31 2317039 Cover, Icemaker
32 489474 Screw
34 489464 Screw
35 626680 Module Assembly
(Includes Items
21 & 41)
37 2306081 Water Valve
Mounting Bracket
41 489136 Screw (2)
43 486194 Screw
44 2300167 Bracket, Icemaker
Mounting
100 2306089 Complete Icemaker
Assembly
Following Parts Not Illustrated
(Optional Parts Only)
8537055 Cleaner,
Stainless Steel
2258232 Ice Container
Assembly
