FREEZER LINER AND AIR FLOW PARTS
For Model: KSSC42FMS01
(Stainless Steel)
8199053
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 2259385 Fan Motor
2 2302850 Support, Air Duct
3 2169142 Fan Blade
4 2223733 Retainer,
Fan Motor
5 2302817 Gasket, Cover
6 2223986 Grommet
7 486194 Screw
8 2259464 Wedge, Air Duct
(Right)
9 488500 Screw, Ground
10 2162085 Socket, Light (2)
11 2221070 Clamp, Nylon
12 2255743 Light Bulb
13 8281185 Screw
14 2182120 Scroll, Fan
15 2259465 Wedge, Air Duct
(Left)
16 2302777 Seal, Light Socket
17 2306043 Assembly, Air Duct
18 2266801 Deflector, Air
Ice Maker
19 Block, Fan Scroll
2209480 Right
2209066 Left
20 2302925 Bracket, Vent Tube
21 Liner (Not
Serviceable Part)
22 2302932 Tube, Vent
23 2259025 Cover, Air Outlet
24 2259367 Light Shield
25 2306049 Cover, Evaporator
26 486194 Screw
27 487539 Screw
29 2306038 Deflector,
Air Duct
30 1112260 Support,
Evaporator
31 2196483 Stud, Shelf (20)
32 8281158 Screw
33 Evaporator,
Cover Rail
2221107 Left Side
2259355 Right Side
34 2220904 Gasket (2)
Evaporator Cover
37 2306052 Gasket, Air Duct
39 2213442 Thermistor
40 2209204 Clip, Thermistor
41 1116793 Cover, Thermistor
42 2006475 Screw
44 2257571 Bracket, Light
46 2259032 Ladder, Shelf
47 2259445 Screw Support (3)
56 2259064 Cover, Fill Tube
Heater
