7
CONTROL PANEL PARTS
For Model: KSSC42FMS01
(Stainless Steel)
8199053
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 2302772 Control Box
2 2215670 Insert, Control
Box
3 2266951 Circuit Board,
Housing Control
4 2187424 Control Box
Wire Harness
6 2221121 Support, Control
Bracket
7 489006 Screw
9 2306086 Display Assembly,
Ingredient Care
Center
11 2162085 Socket, Light (2)
12 2255743 Light Bulb (2)
13 486194 Screw
14 8281185 Screw
15 2257519 Overlay
16 2302717 Shield, Light
To Next Page
