FREEZER DOOR PARTS
16
For Model: KSSC42FMS01
(Stainless Steel)
8199053
Illus. Part
No. No. DESCRIPTION
1 2252327 Freezer Door
(Includes #14)
2 Skin, Door
2306160 Stainless Steel
3 2306398 Plate, Door−Handle
6 2302879 Hinge, Bottom
7 489282 Screw
8 2266854 Hinge, Top
9 2256381 Spacer−Door,
Top
11 2258951 Brace, Door−Corner
14 2222814 Door Gasket,
Magnetic
15 486194 Screw (34)
16 Handle, Door
2005290 Stainless Steel
18 2257637 Door, Spacer
20 Screw
8281250 Stainless Steel
21 2005433 Spacer, Top
23 2004932 Spacer, Door
Bottom
24 2005030 Spacer, Hinge Side
25 308544 Screw
27 2306471 Spacer, Handle
Side
28 2222776 Shelf Bin (6)
34 2005325 Filler, Door
