ICEMAKER PARTS
22
For Model: KSSC42FMS01
(Stainless Steel)
8199053
Illus. Part
No. No. DESCRIPTION
1 2221240 Heater, Fill Tube
2 2221231 Heat Shield
3 2187683 Wire Assembly,
Fill Tube Heater
5 628379 Clip, Fuse
6 2214613 Tube, Filter Inlet
7 2221140 Water Inlet
Tube Assembly
8 1106508 Seal Gasket
9 2302719 Tube, Filter
Outlet
10 2254709 Valve, Solenoid
12 2221070 Clamp, Tube
15 2208136 Clamp, Nylon
Valve
16 488946 Clamp, Tube
17 2300104 Cover−Bottom,
Electrical
18 2257538 Cover
19 1163283 Screw
20 628228 Mold & Heater
(Also Order
542638 Silicone
Grease)
21 627811 Motor
22 628356 Cup−Water Fill
23 627843 Ejector
24 2182124 Ice Stripper
25 2195914 Support
26 627796 Retainer
Thermostat (2)
27 627985 Thermostat
(Also Order
542639 Cement
Alumilastic)
28 8533917 Screw
29 2187715 Wire Assembly,
Icemaker
30 489276 Screw
31 2300169 Shut Off Arm
35 626653 Module Assembly
(Includes Items
21 & 41)
37 2306151 Water Valve
Mounting Bracket
41 489136 Screw (2)
43 486194 Screw
100 2316703 Complete Icemaker
Assembly
Following Parts Not Illustrated
(Optional Parts Only)
2261590 Cleaner,
Stainless Steel
