PARTS AND FEATURES
This manual covers several different models. The features on your dishwasher may vary from those shown below.
A. Model and serial number label
B. Water inlet opening (in tub wall)
C. FLEXI-FOLD DOWN™ flexible tines
(on some models)
D. Detergent dispenser
E. Vent
F. Active v ent
G. Small items basket (on some models)
H. SURE-HOLD
®
light item clips
(on some models)
I. Silverware basket
J. Overfill protection float
K. Heating element
L. Rinse aid dispenser
M. WHISPER QUIET
®
sound
insulation system
N. Control panel located on door
A
B
C
D
E
F
G
H
I
J
K
L
M
N
