PARTS AND FEATURES
Control Panel
1.
Upper spray arm
2.
Top rack
3.
SURE-HOLD™ light item clips
4.
SATINGLIDE
®
upper rack track
5.
FLEXI-FOLD DOWN™
flexible tines
6.
Model and serial number label
7.
Water inlet opening [in tub wall]
8.
4-way HYDRO SWEEP™
spray arm
9.
Bottom rack
10.
Detergent dispenser
11.
Vent system
12.
FLEXI-FOLD DOWN™
flexible tines
13.
SURE-HOLD™ utility shelf
14.
Middle spray arm
15.
Silverware basket
16.
CULINARY CADDY
®
utensil basket
17.
Overfill protection float
18.
Heating element
19.
Rinse aid dispenser
20.
Control panel
Start
Cancel
