PARTS AND FEATURES
This manual covers several different models. The features on your dishwasher may vary from those shown below.
1. Upper spray arm
2. Top rack
3. SURE-HOLD
®
light item clips
4. SATINGLIDE
®
upper rack track
5. FLEXI-FOLD DOWN™ flexible tines
6. Model and serial number label
7. Water inlet opening [in tub wall]
8. 4-way HYDRO SWEEP™
spray arm
9. Bottom rack
10. Detergent dispenser
11. Vent (on some models)
12. Active vent [Model KUDP01FL]
13. FLEXI-FOLD DOWN™ flexible tines
14. SURE-HOLD
®
utility shelf
15. Middle spray arm
16. Silverware basket
17. CULINARY CADDY
®
utensil basket
18. Overfill protection float
19. Heating element
20. Rinse aid dispenser
21. WHISPER QUIET
®
sound
insulation system
22. Control panel located on door front
[Model KUDP01IL]
23. Control panel [Model KUDP01DL]
24. Control panel [Model KUDP01FL]
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
2
0
21
22
2
3
2
4
