Description
Tray
Motor housing
ON/OFF/Reverse Switch
R/ON Switch
Locking knob hole
Locking knob
Stomper
Head
Auger
Part No.
1
2
3
4
5
6
7
8
9
Qty.
1
1
1
1
1
1
1
1
1
Description
1/8’’ Grinding plate
3/16’’ Grinding plate
5/16’’ Grinding plate
Front ring nut
Cutting knife
Stuffing tubes
Kibbe attachment
Head inlet
Part No.
10
11
12
13
14
15
16
17
Qty.
1
1
1
1
1
3
1
1
EXPLODED AND PARTS LIST
