High Power Amp Teaching Resources
www.kitronik.co.uk/2143
The Design Brief
A manufacturer has developed a simple stereo amplifier
circuit. The circuit has been developed to the point where
they have a working Printed Circuit Board (PCB). Although
they are used to the design of High Power Stereo Amplifiers,
they have not designed an amplifier case before.
The manufacturer would like ideas for an enclosure for the
PCB and speakers to be mounted in. The manufacturer has
asked you to do this for them. It is important that you make
sure the final design meets all of the requirements that you
identify for such a product.
Complete Circuit
A fully built circuit is shown below.
