Product Description and Control Panel
1 Salt container 5 Rinse aid dispenser 9 Inlet pipe connector
2 Detergent dispenser 6 Spray arms 10 Drain pipe connector
3 Cutlery basket 7 Cup shelf
4 Filter assembly 8 Basket
1 Power Button: To turn on/off power supply. 3 Delay Button : To press the button to delay.
2 Display screen: to show the reminding time
and the state(running state, delay time etc )
Rinse Aid indicator:
: Indicates when the
dispenser needs to be refilled.
Add salt indicator : Add salt indicator:
Indicates when the dispenser needs to be
refilled.
4 Washing Program Selector: Press the button
to select wash cycles.
5 Start/Pause Button: Press this button to start
or pause the dishwasher.
